- Fastest And Easiest Blade Change On The Market
- 4-Post design with Diagonal Cross Supports provide maximum operational stability
- Interna-Lok Automated Head Clamp Feed Mechanism ensures smooth finishes with minimal snipe
- Indicator Lamp indicates active power supply
- Large Support Table for maximum material support
- Fold Away Depth Adjustment Handle for compact transport and storage
- Flat Top Design facilitates repetitive cutting operations
- On-Board, Detachable Tool Box for operator convenience
STANDARD EQUIPMENT
INCLUDES: 12” Double Edged HSS Planer Blades (793346-8), 2 Ea. Magnetic Holder (762014-4), Socket Wrench 9 (782203-5), Hex Wrench 2.5 (783208-8), Key (415715-0A)
SPECIFICATIONS:
| Cutting Capacities: | |
| Width | 12” (304 mm) |
| Depth | 1/8” (3 mm) |
| Thickness | 6-3/32” (155 mm) |
| Feed Rate Per Minute | 27.9' (8.5 m) |
| No Load Speed | 8,500 RPM |
| AMPS (120V) | 15.0 A |
| Noise Level | 86 dB(A) |
| Table Size (W x L) | 12” (304mm) x 30-3/8” (771mm) |
| Overall Dimensions (W x H x L) | 19” (483mm) x 15-13/16” (401mm) x 30-3/8” (771mm) |
| Net Weight | 61.9 lbs (28.1 kg) |
